Low PIM Log Periodic Antenna
| Electrical Specifications | ||
| Frequency Range | 698-960MHz | 1710-2700MHZ |
| Gain | 10dBi | 11dBi |
| VSWR | ≤2.0 | ≤1.8 |
| Polarization | Vertical | |
| PIM,3rd Order Ratio | ≤-150dBc | |
| Front to Back Ratio | ≥15dB | |
| Horizontal Beamwidth | 70° | |
| Input Impedance | 60° | |
| Max.Power | 50W | |
| Mechanical Specifications | ||
| Connector | N-Female | |
| Dimensions | 440×205×60mm | |
| Packing Size | 480×230×75mm | |
| Weight | 1.1kg | |
| Reflector Material | Brass | |
| Radome Material | ABS (UV Stabilized) | |
| Radome Material | ABS (UV Stabilized) | |
| Rated Wind Velocity | 210km/h | |
| Operating Temperature | -40℃ to +65℃ | |
| Mounting Pole | ￠38-￠52mm | |
